Product model	EMT1
Cargo box Volume	0.5m³
Rated load capacity	1000kg
Unloading height	2100mm
loading height	1200mm
Ground clearance	≥240mm
Turning radius	<4200mm
Wheel track	1150mm
Climbing ability (heavy load)	≤6°
Maximum lift angle of the cargo box	45±2°
Tire model	Front tire 450-14/rear tire 600-14
shock absorption system	Front: Damping shock absorber Rear: 13 thickened leaf springs
Operation   system	Medium plate (rack and pinion type)
Control   system	Intelligent controller
Lighting system	Front and rear LED lights
Maximum   Speed	25km /h
Motor   model/power	AC.3000W
No. Battery	6 pieces, 12V,100Ah maintenance-free
Voltage	72V
Overall dimension	ength3100mm*width     11 50mm*height1200mm
Cargo  box  dimension(outer  diameter  )	Length    1600mm*width    1000mm*height400mm
Cargo box plate thickness	3mm
Frame	Rectangular tube welding
Overall weight	860kg

1. Does the vehicle meet safety standards? Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications. 2. Can I customize the configuration? Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios. 3. Which materials are used in body building? We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments. 4. What are the areas covered by after-sales service? Our extensive after-sales service coverage allows us to support and service customers around the world.We offer a comprehensive after-sales service, including: 1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck. 2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use. 3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time. 4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.For operation, it features a medium plate (rack and pinion type) and an intelligent controller for the control system. The lighting system includes front and rear LED lights. The maximum speed of the truck is 25km/h. The motor has a power of AC.3000W, and it is powered by six maintenance-free 12V, 100Ah batteries, providing a voltage of 72V.The overall dimensions of the truck are: Length 3100mm, Width 1150mm, Height 1200mm. The cargo box dimensions (outer diameter) are: Length 1600mm, Width 1000mm, Height 400mm, with a cargo box plate thickness of 3mm. The frame is made of rectangular tube welding, and the overall weight of the truck is 860kg.The wheel track is 1150mm, and the climbing ability with a heavy load is up to 6°. The cargo box can be lifted to a maximum angle of 45±2°. The front tire is 450-14, and the rear tire is 600-14. The truck is equipped with a damping shock absorber in the front and 13 thickened leaf springs at the rear for the shock absorption system.In summary, the EMT1 mining dump truck is designed for carrying loads of up to 1000kg and is suitable for mining and other heavy-duty operations. It is equipped with a reliable motor and battery system, and its compact size and maneuverability make it well-suited for various mining environments.
